Features
- Suitable for every Video Surveillance and Security application: displays HDMI digital plus VGA inputs
- Auto-on when VGA or HDMI DVR/NVR video is detected
- Bright LED illuminated panel with ultra-wide viewing angle
- Included desk stand is easily removable for standard VESA mounting
- The accessories include HDMI cable and power cable
Specification
General
| Screen diagonal dimension | 21.45 inch |
| Viewable area W x H | 478.656(H) x 260.28(V) |
| Led Type | LED |
| Pixel Pitch | 0.241(H) x 0.241(V) |
| Screen Maximum Resolution | 1920(H) x 1080(V) |
| Supported input Resolutions | 640 x 480; 800 x 600; 1024 x 768; 1280 x 1024; 1920x1080 |
| Refresh Rate(vertical Frequency) | 100Hz |
| Color Depth | 8 bits;16.7Million colors |
| Brightness | 250 cd/m² (max, ± 20%) |
| Monitor Aspect Ratio | 16:9 |
| Horizontal TV Lines | 1080 |
| Contrast Ratio | 1000:1(IPS) |
| Response Time(ms) | 8ms (max) |
| View Angle H/V(degrees) | 178/178 |
| Digital Video Inputs | HDMI up to 1920x1080 |
| Port inputs | BNC IN, HDMI, VGA IN, AUDIO IN, USB IN(FW Upgrade) |
| Port outputs | BNC OUT |
| Speakers | 8Ω 1 Watt/channel |
| OSD Languages | English, Spanish, German, Chinese, French, Italian |
| Dimensions (W x L x D) (mm) | 492.7 x 280.9 x 50.8mm |
| Packing size (mm) | 560 x 114 x 398mm |
| Case & stand material | Plastic |
| VESA Mounting Pattern | 75 x 75mm; location centered on monitor body |
| Base/Stand included | Yes |
| Net Weight | 2.88kg |
| Gross Weight | 3.78kg |
| Power- Watts(on and standby) | < 22W(STB 0.5W) |
| Power input | 100 ~ 240V AC |
| Operating Temperature | 0°C~ 40°C |
| Storage Temperature | -20°C ~ 60°C |
| Operating Humidity | 10%~ 85% |
