下載技術規格
產品資訊
- 功率限制控制
- 適用於單線電話
- 適用於安全系統
技術規格
General
| Conductor | Material | TC |
| Cores | 2 | |
| Max Resistance(20°C) | 52 Ω/km | |
| Construction(No./mm) | 7 / 0.25 mm | |
| Insulation | Insulation | PVC |
| Insulation Dielectric | 2.1 mm ± 0.1 mm | |
| Insulation Color | White & Black | |
| AL Foil | AL Foil | |
| Shield | Drain wire(No./mm) | 7 / 0.25 mmTC |
| Jacket Material | LSZH | |
| Jacket | Jacket Color | Grey |
| Jacket Thickness | 0.85 mm ± 0.05 mm | |
| Jacket O.D | 5.4 mm ± 0.2 mm | |
| Operation Temperature | -20 °C ~ +60 °C | |
| Length | 200 Yards / 300M | |
Construction
