產品資訊
- 功率限制控制
- 適用於單線電話
- 適用於安全系統
技術規格
General
| Conductor | Material | TC |
| Cores | 4 | |
| Max Resistance(20°C) | 80 Ω/km | |
| Construction(No./mm) | 7 / 0.2 mm | |
| Insulation | Insulation | PVC |
| Insulation Dielectric | 1.1 mm ± 0.1 mm | |
| Insulation Color | White, Black, Orange, Red | |
| AL Foil | / | |
| Shield | Drain wire(No./mm) | / |
| Jacket Material | LSZH | |
| Jacket | Jacket Color | White |
| Jacket Thickness | 0.6 mm ± 0.05 mm | |
| Jacket O.D | 4.1 mm ± 0.2 mm | |
| Operation Temperature | -20 °C ~ +60 °C | |
| Length | 200 Yards / 300M |
Construction
