PC6A
Catalogue6A S/FTP Patch Cord
Price: HK$0
download-icon Download Specification
Features
  • Conductor: 26 AWG
  • Standard:

      ISO/IEC 11801:2011(Ed. 2.2), ANSI/TIA- 568-C.2

  • Applications :

      Data communications, Local area networks, Building signaling systems

  • ISO9001Certified Manufacturing Plant
  • Length: 0.15M / 0.3M / 0.6M / 1M / 1.5M / 2M / 3M / 5M / 8M / 10M / 12M /15M
Specification

Standard

Standard

ISO/IEC 11801, ANSI/TIA- 568-C2

ISO9001Certified Manufacturing Plant



General

Conductor  Material Stranded-Bare Copper
  Nom. O.D. (mm) 26AWG (7/0.16)
Insulation Material PE
  Diameter 1.02±0.0 5 mm
Sheath Thickness  0.58±0.05 mm
  External O.D.(Avg.)  6.2±0.2 mm
  Surface  Clean,Frap,Satiation
  Material PVC(complies RoHS)
Operation Temperature   -25 to 60°C
Sheath Physical Properties Tensile Strength (kg/mm2)  ≧1.05
  Elongation (%)  ≧100
Electrical Characteristics (20°C) Durability  ≧1200 matching cycle
  Max Pull Tension 90 N
  Current Rating 1.5A
  Insulation Resistance 100 MΩ min
  Contact Resistance 20 MΩ max
  Dielectric Strength 500 VAC (rms)
  Voltage 72 VDC max


Electric Performance

Frequency (MHz)

Insertion Loss

(max.dB)

Limit dB

Next

(max.dB)

Limit dB

Return Loss

(max.dB)

Limit dB

PSNEXT

(max.dB)

Limit dB

ACR-N

(max.dB)

Limit dB

PS ACR-N

(max.dB)

Limit dB

ACR-F

(max.dB)

Limit dB

PS ACR-F

(max.dB)

Limit dB

1 3 65 19 62 65 59 63.3 60.3
4 4.2 63 19 60.5 58.9 56.4 51.2 48.2
8 5.8 58.2 19 55.6 52.4 19.8 45.2 42.2
10 6.5 56.6 19 54 50.1 17.5 43.3 40.3
16 8.2 53.2 18 50.6 45 42.4 39.2 36.2
20 9.2 51.6 17.5 49 42.5 39.8 37.2 34.2
25 10.2 50 17 47.3 39.8 37.1 35.3 32.3
31.25 11.5 48.4 16.5 45.7 36.9 34.2 33.4 30.4
62.5 16.4 43.4 14 40.6 27 24.2 27.3 24.3
100 20.9 39.9 12 37.1 19 16.2 23.3 20.3
200 30.1 34.8 9 31.9 4.7 1.8 17.2 14.2
250 33.9 33.1 8 30.2 -0.8 -3.7 15.3 12.3
300 37.4 31.7 7.2 28.8 -5.6 -8.6 13.7 10.7
400 43.7 28.7 6 25.8 -14.9 -17.9 11.2 8.2
500 49.3 26.1 6 23.2 -23.2 -26.1 9.3 6.3
