Features
- Modern, optimised design to achieve optimum gain / size ratio
- Active/passive dipole
- Self-adapting: provides a constant, balanced signal, minimising loss and maximising adaptation
- Lightweight and robust, designed with state-of-the-art technology to guarantee an excellent response and a long lifetime
- High quality plastic with special UV protection
- Easy installation, in just 3 clicks, no tools needed
- Compact, small-sized single-unit packing
- Simple, ergonomic mast fixing system to guarantee secure mounting
Specification
General
| Channels | 21~48 |
| Gain | 14 dB |
| Impedance | 75 ohm |
| Back-to-front-ratio | 24 dB |
| Horizontal opening angle | 25 º<) |
| Noise figure | 2 dB |
| Packing dimensions (1UN) | 600 x 400 x 690 mm |
| Weight | 10 Kg |
