1920
Speaker Cable
Price: HK$0
download-icon Download Specification
Features
  • Intercom / PA systems
  • Sound / Audio systems
  • LSZH Jacket option available
Specification


General

Conductor Material TC
  Diameter (mm) 19/0.2
  Max Resistance(20°C) 29Ω/km
  Construction (mm) 2x19/0.2
Insulation Insulation PVC
  Insulation Thickness ---
  Insulation Diameter )mm) 2.0±0.05
  Insulation Color White, Black
Jacket Jacket Material PVC
  Jacket Color Grey
  Jacket Thickness (mm)  0.9±0.05
  Jacket O.D (mm) 5.8±0.1
Drain Wire ---
Shield   ----
Operation Temperature -20C to +70°C
Working voltage 300/300V


Construction



Self Photos / Files - 1920Construction
