Features
- HDMI1.4, HDCP1.4 compliant
- Built-in EDID to ensure HDMI signal transmission from source to display
- Extends 1080P @60Hz signal up to 100m (Cat6)
Specification
General
| Standards | HDMI 1.4; HDCP1.4 |
| bandwidth | 225MHz |
| Data rate | 10.2Gbps |
| Resolution | 3840 x 2160@30Hz |
| Connector | HDMI-A |
| Impedance | 100 Ω |
| Interface | RJ45 |
| Transmission distance | CAT6---100M ; CAT5E---80M |
| Power supply | 12V / 1A |
| Power dissipation | MAX 3.6W |
| Temperature | Operating: -5°C ~ +70°C |
| Humidity | Operating: 5% ~ 90% |
| Dimension | 81.5 x 45.5 x 23 mm |
