Download Specification
Features
- Frequency: 470-694 MHz
- Channels: C21-48
- Gain: 14dB
- High quality extrusion aluminum antennas
- Click clack mechanism
- Directors robustly attached to the central axle
- Anti corrosion plastic
- Shielded “F” connector (75Ω), ideal against impulsive noise
Specification
General
| Frequency Rang | 470-694MHz |
| Channels | 21 - 48 |
| Directors | 21 |
| Max Gain (dB) | 14 |
| Beamwidth H/V | 30 / 35 |
| Front/Back Ratio | 25 |
| Polarization Adjustment | H - V |
| Windload (170Km/h) | --- |
| Length (m) | 1.274 |
| Weight (Kg) | 2.2 |
