Download Specification
Features
- Power limited controls
- Single line telephone
- Security systems
Specification
General
| Conductor | Material | TC |
| Cores | 8 | |
| Max Resistance(20°C) | 80 Ω/km | |
| Construction(No./mm) | 7 / 0.2 mm | |
| Insulation | Insulation | PVC |
| Insulation Dielectric | 1.1 mm ± 0.1 mm | |
| Insulation Color | White, Black, Orange, Red, Blue, Green, Yellow, Brown | |
| AL Foil | / | |
| Shield | Drain wire(No./mm) | / |
| Jacket Material | LSZH | |
| Jacket | Jacket Color | White |
| Jacket Thickness | 0.65 mm ±0.05 mm | |
| Jacket O.D | 5.1 mm ± 0.2 mm | |
| Operation Temperature | -20 °C ~ +60 °C | |
| Length | 200 Yards / 300M | |
Construction
